# Example 03: Basic Plots

This week there is less coding in the lectures because we’re thinking about graphs in a more general way. But the problem set wants you to practice some basic plotting, and ideally experiment a little as well. Here are some examples to get you started.

We begin as usual by loading the `tidyverse` package.

Code
``library(tidyverse)``

## Review

Remember, in R, everything has a name and everything is an object. You do things to named objects with functions (which are themselves objects!). And you create an object by assigning a thing to a name.

Assignment is the act of attaching a thing to a name. It is represented by `<-` or `=` and you can read it as “gets” or “is”. Type it by with the `<` and then the `-` key. Better, there is a shortcut: on Mac OS it is `Option -` or Option and the `-` (minus or hyphen) key together. On Windows it’s `Alt -`.

You do things with functions. Functions usually take input, perform actions, and then return output.

Code
``````# Calculate the mean of my_numbers with the mean() function
my_numbers <- c(1,5,7,2,16,31,3,6,9)
mean(x = my_numbers)``````
``[1] 8.888889``

The instructions you can give a function are its arguments. Here, `x` is saying “this is the thing I want you to take the mean of”.

If you provide arguments in the “right” order (the order the function expects), you don’t have to name them.

Code
``mean(my_numbers)``
``[1] 8.888889``

To draw a graph in ggplot requires two kinds of statements: one saying what the data is and what relationship we want to plot, and the second saying what kind of plot we want. The first one is done by the `ggplot()` function.

Code
``````ggplot(data = mpg,
mapping = aes(x = displ, y = hwy))``````

You can see that by itself it doesn’t do anything.

But if we add a function saying what kind of plot, we get a result:

Code
``````ggplot(data = mpg,
mapping = aes(x = displ, y = hwy)) +
geom_point()``````

The `data` argument says which table of data to use. The `mapping` argument, which is done using the “aesthetic” function `aes()` tells ggplot which visual elements on the plot will represent which columns or variables in the data.

Code
``````# The gapminder data
library(gapminder)
gapminder``````
``````# A tibble: 1,704 × 6
country     continent  year lifeExp      pop gdpPercap
<fct>       <fct>     <int>   <dbl>    <int>     <dbl>
1 Afghanistan Asia       1952    28.8  8425333      779.
2 Afghanistan Asia       1957    30.3  9240934      821.
3 Afghanistan Asia       1962    32.0 10267083      853.
4 Afghanistan Asia       1967    34.0 11537966      836.
5 Afghanistan Asia       1972    36.1 13079460      740.
6 Afghanistan Asia       1977    38.4 14880372      786.
7 Afghanistan Asia       1982    39.9 12881816      978.
8 Afghanistan Asia       1987    40.8 13867957      852.
9 Afghanistan Asia       1992    41.7 16317921      649.
10 Afghanistan Asia       1997    41.8 22227415      635.
# ℹ 1,694 more rows``````

A histogram is a summary of the distribution of a single variable:

Code
``````ggplot(data = gapminder,
mapping = aes(x = lifeExp)) +
geom_histogram() ``````
```stat_bin()` using `bins = 30`. Pick better value with `binwidth`.``

A scatterplot shows how two variables co-vary:

Code
``````ggplot(data = gapminder,
mapping = aes(x = gdpPercap, y = lifeExp)) +
geom_point() ``````

A boxplot is another way of showing the distribution of a single variable:

Code
``````ggplot(data = gapminder,
mapping = aes(y = lifeExp)) +
geom_boxplot() ``````

Boxplots are much more useful if we compare several of them:

Code
``````ggplot(data = gapminder,
mapping = aes(x = continent, y = lifeExp)) +
geom_boxplot() ``````
